Motor
Giant SyncDrive Pro2 85Nm, PedalPlus 6-Sensor technology
Controller
Giant RideControl Ergo3, grip integrated remote
Display
Giant RideControl GO, frame integrated LED console Optional wireless ANT+ display
Battery
Giant EnergyPak 750Wh, Lithium cell technology, Aluminium casing with highest safety standard (EN50604), CO2 Neutral production Giant EnergyPak Plus 250 range extender compatible
Charger
Giant EnergyPak 6A smart charger, 60% in 3:00h
Connectivity
Giant RideControl App enabled ANT+ wireless display signal with e-bike profile
Sizes
S, M, L, XL
Colours
Gloss Cordovan/Copper Coin
Frame
ALUXX SL-grade Aluminium, Advanced Forged Composite linkage, 140mm Maestro Suspension System, 'Boost' 148x12 UDH rear axle, Giant EnergyPak Plus Range Extender Compatible
Fork
RockShox 35 Gold RL DebonAir, 150mm travel, 44mm offset, MotionControltm rebound and lockout control, 15x110 Boost, Maxle Stealth, e-MTB optimised
Shock
Rock Shox Deluxe Select R, DebonAir, 185x52.5mm Trunnion mount, custom tuned, recommended sag: 30%
Handlebar
Giant Contact 35 Trail, 35x780mm
Grips
Giant Tactal Pro-E, tapered design, 135mm Ø28~30mm (S/M) 142mm Ø29~32mm (L/XL)
Stem
Giant Contact SL 35
Seatpost
Giant Contact Switch, dropper, 30,9mm (S:125mm, M:150mm, L/XL:170mm)
Saddle
Giant Romero
Pedals
Flatpedal
Shifters
Shimano Deore 1x12
Front Derailleur
MRP HD2 co-moulded chain guide
Rear Derailleur
Shimano Deore, 12-speed
Brakes
Shimano BR-M420, 4-piston, hydraulic disc, 203mm
Brake Levers
Shimano Deore, I-spec EV
Cassette
Shimano CS-M6100-12, 10-51T, 12-speed
Chain
KMC e.12 Turbo, EcoProteq, e-bike optimised
Crankset
Praxis Wave tm 36T Cold Forged 4130 premium steel chain ring 104BCD Praxis e-crank arm set (S:160, M/L:165, XL:170) Q-factor=168mm, Chainline: 55mm, Max Chainring: 38T
Bottom Bracket
n/a
Rims
Giant AM 29", Tubeless ready, 30mm inner width
Hubs
Shimano MT410 Boost, Center-Lock, [F] 110x15 [R] 148x12mm Micro-Spline Drive Body Thru-axle
Spokes
Sapim E-Lite [R] Race [F], e-bike optimised
Tyres
Maxxis Minion DHF 29x2.6" foldable, Tubeless, EXO+, 3C MaxxTerra [F]Maxxis Dissector 29x2.6" Foldable, Tubeless, EXO+, 3C MaxxTerra [R]
Extras
Tubeless kit (liquid, valves, levers, manual, tool)
Lock
Torx 25 Battery Lock with built-in Torque limiter
Weight
The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality
